Wiring harnesses / Speed converters / Immobilizer removal box

8 Questions View all

Where should I run the wire for the boost solenoid

Have the conversion harness just wanted to know where to put the wire for the boost solenoid?

Answer this question I have this problem too

Is this a good question?

Score 0
Add a comment

1 Answer

Wiring the Hondata Boost Control Solenoid

The solenoid has two wires, with no polarity (it does not matter which wire is used for each connection):

  • One wire should be connected to the ECU pin B21 (which normally runs the purge control solenoid on the throttle body).
  • One wire should be connected to +12V switched power via a 10A fuse.

Notes:

  • Do not use a relay between the ECU and solenoid.
  • High current solenoids could damage the ECU.

Was this answer helpful?

Score 0
Add a comment

Add your answer

Kaiyah jhay will be eternally grateful.
